Industrial flow cans
Reference photos rebuilt as manufacturable CAD with corrected flow paths.
02Approach
Outer geometry was rebuilt from the photographs against known reference dimensions. The internal path was then modelled properly rather than copied, with the restrictions in the original removed.
03Result
A manufacturable model and drawings for a part that had no source files, with the flow path corrected in the rebuild.
