Bite block
Open frame that spreads occlusal force and holds instruments steady.
MD-03 · Render 0202Approach
The open frame came first, leaving few closed pockets for debris. Triangular arms with eyelets at their tips give the attachment points, and a graduated slide with a pull ring adjusts the fit. Wall sections were sized for 3D printing.
03Result
A printable model of the flange, bite channel, curved tongue plate and graduated slide, so a trial piece can be made and handled before the design is fixed.
