CAD design studio

Where ideas take form.

If you can describe it, we can draw it. Send a sketch, a photo or a broken part, and get back CAD a shop can build from.

Start a projectSee the work
Selected work01

Drawn to be made.

From a walking robot to a hair dryer. Each one left as files a shop could quote from.
Multi-terrain robotic platformRB-01 Military gradeMulti-terrain robotic platformWalking legs plus a caterpillar track, with modular payload mounts.SectorRoboticsStarted fromAn ideaDeliveredSTEP · Native · 2D drawings · BOMCustom-fit arm castMD-01 MedicalCustom-fit arm castAutomatic roadside bollardRD-02 R&DAutomatic roadside bollardIndustrial flow cansRE-01 Reverse eng.Industrial flow cansAnywhere Curls hair dryerHF-03 HomeAnywhere Curls hair dryer
All work, 24 projects
In numbers02

The studio, measured.

Projects deliveredRed: 24 on this site

Three hundred squares, one for each project delivered. The red ones are on this site.

012345678901234567890123456789+
Tolerance heldMedical parts
±0123456789.01234567890123456789mm
  • Fixed priceAgreed before we start
  • 3 revision roundsIncluded in every price
  • You own the filesEvery file, every drawing
How it works03

Bring us the thing you can't explain.

A sketch on a napkin. A part that snapped. A shape you can only describe with your hands. That is enough to start.
Shown One ring gear assembly, from sketch to shop drawingHover a stage to draw it again
01Sketch
  • From your description
  • Not to scale

Design

We sit with your idea until it has edges. Sketches become dimensioned geometry you can react to before anything is committed.

02Model
  • Parametric CAD
  • 277 × 312 × 279 mm

Develop

Parametric CAD built to be made. Tolerances, wall thickness, draft angles and material behaviour are decided on purpose.

03Drawing
  • Sheet 1 of 1
  • Scale 1:4 · mm

Deliver

Native files, STEP, IGES, STL and 2D drawings. Everything a machine shop needs, and you own all of it.

Delivered asSTEPIGESSTLNative2D drawings
How the studio works
Sectors04

Different rules. Same method.

Medical, robotics, consumer, play. The vocabulary changes. The work underneath stays the same.
Medical materials PEEK · 316L · Medical polymerTypical work Surgical and clinical
Terms05

No surprises.

Intellectual property

You own everything.

Every file, every drawing, every revision. No licence back to us.

Confidentiality

NDA on request.

Signed before you send us anything. Ask and it goes out the same day.

Quoting

Fixed price, agreed up front.

Describe the idea, we scope it, you get a number. No hourly surprises.

Turnaround

Single part 3 to 7 days. Assembly 2 to 5 weeks.

Quoted with a date before we start. If it slips, you hear it from us first.

Revisions

Three rounds included.

Most projects use two. Beyond three, hourly, quoted before the work.

Formats

STEP, IGES, STL, native, 2D drawings.

Whatever your manufacturer asks for. If it is not on this list, ask.
